Features

• BNC to 4 mm Test Leads: Facilitate the connection between the oscilloscope and various signal types, with color-coded connectors for accurate testing.
• 6-way Breakout Leads: Enable testing of multiple sensors and actuators, including MAP, temperature, throttle position, and airflow sensors, as well as fuel pumps and injectors.
• USB Cable: Connects the Scopebox to the diagnostic tool, allowing sampled signals to be displayed and analyzed.
• Battery Clamps Cable: Provides power to the Scopebox by connecting to the vehicle’s battery.
• 20:1 Attenuator: Allows measurement of fuel injector and primary ignition waveforms. Note: Should not be used for high-voltage measurements other than fuel injectors and primary ignition.
• Secondary Ignition Pick-up: Used for analyzing secondary-distributor ignition, simultaneous ignition, and direct ignition systems.
• COP (Coil-on-Plug) Extension Cord: Enables accurate secondary ignition measurements on coil-on-plug systems, especially when access to spark plug leads is limited.
• Multimeter Probes: Essential for various electrical measurements and diagnostics.
• Crocodile Clips: Designed to connect to bare terminals or leads securely.
• Back Probe Pins Suite: Allows for piercing wire insulation to perform electrical measurements without causing damage; also usable as pin-tip probes for small circuit boards.
