$649.95
ERP CODE: 301180847
In stock
Launch S2-2 Sensorbox
The new Launch’s S2-2 Sensorbox is designed to test and simulate most vehicle sensors, quickly troubleshooting the ECU. It can be compatible with Launch scanner X431 Throttle III, X431 Throttle, to maximize repair shop revenue.
• Number of Channel: 2
• Voltage Simulation Range: 0 to 20 V
• Maximum Output Current: 20 mA
• Square Wave Signal Pulse Frequency: 0 to 15 kHz
• Square Wave Signal Duty Cycle: 0 – 100%
• DCV Simulation: Support
• Multimeter: Support
• Operating Temperature 0℃~ 50℃
• Storage temperature -30℃~70℃
• Certificate: CE, FCC, RoHS
• Weight: 14.7 lbs
• Compatible with X-431 Throttle & X-431 Throttle III
• ECU Troubleshooting and Diagnostics
• It supports manual write the waveform data
• Simulate working condition of sensors without replacing parts
◦ Throttle & Pedal Sensor
◦ Airflow Meters
◦ Oxygen Sensor
◦ Temperature Sensor
◦ EGR Sensor
◦ Injectors Sensor
◦ Crank
◦ Cam sensors inductive & hall
• Be used as Multimeter to measure resistance, voltage AC/DC, capacitance, frequency and pulse signals, etc.
• Simulate some special working condition of sensors without replacing parts
• One click to enters the intuitive menu of sensor, actuator, defined/drawn the waveform, timing waveform, multimeter, system settings (working with scanner)
