Pico Technology PicoScope 4425A 4-Channel Diesel Kit (PQ179)

Pico PQ179 Diesel Kit

$3,341.00

In stock

SKU: PQ179 Category: Tags: , , , , Brand:

Description

The PQ179 – PicoScope Diesel Kit is a specialized diagnostic package designed for advanced testing of diesel engines across passenger, light commercial, and heavy-duty vehicles. Built around the 4-channel PicoScope 4425A, this kit provides essential tools for analyzing high-pressure fuel systems, injectors, turbocharging systems, and more. It includes a WPS500X pressure transducer, current clamps, breakout leads, and PicoBNC+™ accessories for smart connectivity and accurate measurement.

• High-pressure diesel diagnostics: Includes WPS500X pressure transducer and fuel adapters to monitor and diagnose common-rail and older diesel systems.
• Smart test leads and sensors: PicoBNC+™ leads auto-configure in PicoScope software for streamlined setup and accurate data capture.
• Current clamps and breakout leads: Enables injector and pump current testing to evaluate electrical and mechanical operation.
• Versatile testing capability: Suitable for EGR valves, glow plugs, turbochargers, cam/crank signals, and more.
• Durable and organized: Comes in a heavy-duty carry case with custom foam inserts for field and shop use.

This kit is ideal for diesel specialists and workshops aiming to reduce diagnostic time and improve repair accuracy on a wide range of diesel platforms.

Specifications

  • Oscilloscope: PicoScope 4425A, 4-channel
  • Pressure Transducer: WPS500X, ±500 psi range
  • Current Clamps: 60A and 2000A PicoBNC+ AC/DC clamps
  • Test Leads: PicoBNC+ 3m color-coded leads (Red, Blue, Green, Yellow)
  • Accessories: Fuel line adapters, battery clips, breakout leads
  • PC Interface: USB 2.0, PicoScope Automotive Software

Features

  • Non-intrusive diagnostics for common-rail and unit injector systems
  • High-speed waveform capture for accurate signal analysis
  • PicoBNC+ smart probe detection and auto-scaling
  • Measurement of injector balance, timing, and activation current
  • Live pressure testing of fuel rail and boost systems
  • Works with both 12V and 24V diesel applications

Applications

  • Fuel pressure diagnostics and leak-down testing
  • Injector circuit and performance analysis
  • Glow plug current testing
  • EGR and turbo actuator control signal verification
  • Crankshaft and camshaft sensor synchronization
  • Heavy-duty diesel and commercial fleet diagnostics

Package Contents

PN DESCRIPTION QTY
MI121 USB 2.0 Cable: PicoScope – blue, 4.5m 1
MI168 S hook 2
PA038 QuadroPack telescopic plastic case 2
PA209 Carry Case: 4425A Standard Case 1
PQ174 PicoScope 4425A 4ch Scope only, w/USB cable 1
TA310 Multimeter Style Test Probe – black 2
TA311 Multimeter Style Test Probe – red 2
TA003 Small crocodile clip – black 2
TA004 Small crocodile clip – red 2
TA008 Back-Pinning Probe set 1
TA012 2 wire break out lead 1
TA017 4mm shrouded to unshrouded adaptor red 4
TA034 ATC/ATO Fuse Extension Lead 1
TA035 Mini Fuse Extension Lead 1
TA157 Battery clip 4mm socket (red) 2
TA158 Battery clip 4mm socket (black) 2
TA161 Flexible back pinning probe (black) 4
TA162 Flexible back pinning probe (red) 4
TA168 JCASE Fuse Extension Lead 1
TA190 2-pin ACS Connector breakout lead 1
TA191 3 pin Kostal Connector breakout lead 1
TA206 Maxi Fuse Extension Lead 1
TA329 Ultrasonic parking sensor detector 1
TA330 Keyless entry carrier signal detector 1
TA388 PicoBNC+ Current Clamp: 2000A AC/DC 1
TA475 PicoBNC+ Test Lead: 4mm permanent ground 5m blue 1
TA476 PicoBNC+ Test Lead: 4mm permanent ground 5m red 1
TA477 PicoBNC+ Test Lead: 4mm permanent ground 5m green 1
TA478 PicoBNC+ Test Lead: 4mm permanent ground 5m yellow 1
TA473 PicoBNC+ Current Clamp: 60A AC/DC 1
TA506 PicoBNC+ 10:1 Attenuating Test Lead 2
